| Production Information |
| Item Name |
- Kinugawa Oil Return Flange - Garrett T3/T4/T04B/T04E 3/4" Barb
|
| Application |
- Garrett T3, T4, T04B, T04E turbo
|
| Specification |
- Bolt spacing : 50.8mm
- Bolt hole dia : M8
- Female 1/2PT on the flange
- 3/4" Rubber hose / OD 19.6mm Rubber hose
|
| Material |
|
| Kit Includes |
- 1 x oil return flange
- 1 x oil return gasket
- 2 x M8 bolt with spring washer
- 1 x 1/2PT to 3/4" barb fitting
|
| Made By |
|
| Warranty |
|
Please note, due to the number of turbo configurations, and a large variety of fitting kits, Kinugawa orders are custom made to order (please allow 7-10 working days)
